Crossista F7

D342 DISC
Sram Rival - RED CX

FOR THOSE WHO RIDE THROUGH MUD AND OBSTACLES: IMPASSABLE!

The Crossista is our weapon dedicated to Cyclocross competitions. On this model the geometries have been optimized and the rear triangle is equipped with “flex stays” technology ensuring precise handling in the technical sections of the most difficult tracks. The main triangle is shaped to optimise ergonomics while carrying the bicycle on the shoulder when overcoming obstacles and the tubes profiles have been designed to minimize mud accumulation. Thanks to the combination of maximum performance and versatility, Crossista F will guide you to victory.

Crossista F7
Innovation
ITALIAN BB
RACE GEOMETRY
CARBON T700 UD
ASYMMETRIC FRAME
FORK FLAP
ONDA TOP TUBE
ONDA FORK
CARBON T700 <span>UD</span>



milestones

CARBON T700 UD

The secret of T700 Toray Carbon is to maintain reactivity and performances but to offer a higher dampening to absorb all road vibration. More comfort, more fun.

ONDA FORK





milestones

ONDA FORK

A distinctive Pinarello Technology since 2000. The shape of the fork delivers precise turning abilities, stability and reduction of longitudinal and lateral shocks.

ONDA TOP TUBE



ONDA TOP TUBE

Shoulder your bike with ease thanks to the ergonomic top tube designed specifially for this demanding discipline

Geometries

CE CC L A [°] B [°] P T D R G REACH STACK
480 490 510 75 70.5 425 106 65 50 402 360.4 537.5
495 505 525 74.5 71 425 124 65 50 402 366 556.5
510 520 540 74 71 425 141 65 50 402 371.6 572.5
530 540 555 73.5 71 425 161 65 50 402 376.3 591.4
550 560 570 73 72 425 176 65 50 402 382.2 609.7
570 580 585 72.5 72 425 193 65 50 402 387 625.9
Crossista F7 Geometry

CE: SEAT TUBE CENTER - END, CC: SEAT TUBE CENTER - CENTER, L: TOP TUBE CENTER - CENTER, A[°]: SEAT TUBE ANGLE, B[°]: HEADTUBE ANGLE, P: CHAINSTAY, T: HEADTUBE, D: BB DROP, R: FORK RAKE , G: FORK HEIGHT, REACH, STACK

ALL COMPONENTS

FRAME SET
FRAME
Torayca T700 UD, TiCR™ internal cable routing, Italian BB, UCI approved
FORK
Crossista Onda Fork with ForkFlap™, Tapered head tube
DRIVETRAIN
CRANKSET AND CHAINRINGS
SRAM Rival 12S
FRONT DERAILLEUR
SRAM Rival 12S
REAR DERAILLEUR
SRAM Rival 12S
CASSETTE
SRAM Rival 12S
CHAIN
SRAM Rival 12S
BOTTOM BRACKET
SRAM Rival 12S
BRAKES
FRONT BRAKE DISC
Sram Rival 2 pistons, 140mm rotor
REAR BRAKE DISC
Sram Rival 2 pistons, 140mm rotor
COCKPIT
HANDLEBAR
Jaguar XA Aero TiCR
STEM
Tiger Aero Alu TiCR
BAR TAPE
MOST Ultragrip Evo 3mm - Black
SADDLE
Most Lynx Aircross FEC Alloy Large 145mm
SEATPOST
Pinarello Aero Seatpost
SEAT CLAMP
fsc frontal seat clamp
WHEELS AND TIRES
TYRES DISC
maxxis aggressor 700c, max tyre size 42mm (width as measured)
WHEELSET DISC
Fulcrum Racing 500
AXLES DISC
pinarello axle 12x100 & 12x142, tool free removal
