Crossista F9

G430 DISC
Shimano Ultegra Di2 12V - CROSS BLACK
G431 DISC
Shimano Ultegra Di2 12V - LIZZARD GREEN
D340 DISC
Shimano Ultegra Di2 12V - PIDCOCK REPLICA
D341 DISC
Shimano Ultegra Di2 12V - TBLACK CX

FOR THOSE WHO RIDE THROUGH MUD AND OBSTACLES: UNSTOPPABLE!

The Crossista is our weapon dedicated to Cyclocross competitions. On this model the geometries have been optimized and the rear triangle is equipped with “flex stays” technology ensuring precise handling in the technical sections of the most difficult tracks. The main triangle is shaped to optimise ergonomics while carrying the bicycle on the shoulder when overcoming obstacles and the tubes profiles have been designed to minimize mud accumulation. Thanks to the combination of maximum performance and versatility, Crossista F will guide you to victory.

Crossista F9
Innovation
ITALIAN BB
RACE GEOMETRY
ASYMMETRIC FRAME
FORK FLAP
ONDA TOP TUBE
ONDA FORK
CARBON T900 UD
CARBON <span>T900 UD</span>



milestones

CARBON T900 UD

The right balance between reactivity, dampening capabilities and lightness for competition.

ONDA FORK





milestones

ONDA FORK

A distinctive Pinarello Technology since 2000. The shape of the fork delivers precise turning abilities, stability and reduction of longitudinal and lateral shocks.

ONDA TOP TUBE



ONDA TOP TUBE

Shoulder your bike with ease thanks to the ergonomic top tube designed specifially for this demanding discipline

Geometries

CE CC L A [°] B [°] P T D R G REACH STACK
480 490 510 75 70.5 425 106 65 50 402 360.4 537.5
495 505 525 74.5 71 425 124 65 50 402 366 556.5
510 520 540 74 71 425 141 65 50 402 371.6 572.5
530 540 555 73.5 71 425 161 65 50 402 376.3 591.4
550 560 570 73 72 425 176 65 50 402 382.2 609.7
570 580 585 72.5 72 425 193 65 50 402 387 625.9
Crossista F9 Geometry

CE: SEAT TUBE CENTER - END, CC: SEAT TUBE CENTER - CENTER, L: TOP TUBE CENTER - CENTER, A[°]: SEAT TUBE ANGLE, B[°]: HEADTUBE ANGLE, P: CHAINSTAY, T: HEADTUBE, D: BB DROP, R: FORK RAKE , G: FORK HEIGHT, REACH, STACK

ALL COMPONENTS

FRAME SET
FRAME
TorayCa T900 UD, TiCR™ cable routing, Italian BB, UCI approved
FORK
Crossista Onda Fork with ForkFlap™, Tapered head tube
DRIVETRAIN
CRANKSET AND CHAINRINGS
Shimano Ultegra Di2 RD R8150 2S
FRONT DERAILLEUR
Shimano Ultegra Di2 FD R8150 12S
REAR DERAILLEUR
Shimano Ultegra Di2 RD R8150 2S
CASSETTE
CHAIN
Shimano Ultegra CN-M8100 12S
BOTTOM BRACKET
shimano ultegra
BRAKES
FRONT BRAKE DISC
Shimano Ultegra R8150, 2 pistons caliper, 160mm rotor
REAR BRAKE DISC
Shimano Ultegra R8150, 2 pistons caliper, 140mm rotor
COCKPIT
HANDLEBAR
Jaguar XA Aero Di2
STEM
Tiger Aero Alu TiCR
BAR TAPE
MOST Ultragrip Evo 3mm - Black
SADDLE
Most Lynx Aircross FEC Alloy Large 145mm
SEATPOST
Pinarello Aero Seatpost
SEAT CLAMP
fsc frontal seat clamp
WHEELS AND TIRES
TYRES DISC
maxxis aggressor 700c, max tyre size 42mm (width as measured)
WHEELSET DISC
MOST Ultrafast 40*
AXLES DISC
pinarello axle 12x100 & 12x142, tool free removal

COMPARE MODELS

Crossista F9
Crossista F9
Crossista F7
Crossista F7
Crossista F9
Crossista F9
Crossista F7
Crossista F7
FRAME SIZES 6 6
FRAME TorayCa T900 UD, TiCR™ cable routing, Italian BB, UCI approved Torayca T700 UD, TiCR™ internal cable routing, Italian BB, UCI approved
GROUPSET Shimano Ultegra Di2 12V Sram Rival
WHEELSET DISC MOST Ultrafast 40* Fulcrum Racing 500
RIM
